Sziasztok!
Kaptam egy gányolt erőlködőt,először beakartam dobni a többi lom közé...de miután kicsit megvizsgáltam és kiderült a panelja sértetlen,végfokok eredetiek és hibátlanok úgy döntöttem helyre pofozom.Hangerő gombja hiányzik de van esztergám, meg képem az eredetiről ez nem probléma,még a venti lyukat kell szépen eltüntetni a hátuljáról.Lesz vele pár óra munka de imkább mint hogy hulladékként végezze.
A legnagyobb gond hogy valami "mester" belefabrikált 2 db kisebb toroid trafót(OLP 3D817)+ventillátort mellé(gondolta a kis trafók majd bírják árammal ezt az erősítőt ha hűti őket)amik szépen primer zárlatosak is lettek.Kerestem neten de sehol nem találok róla rajzot(tanyán sem) hogy milyen feszültségeket szolgáltathatott eredetileg.Ránézésre 2 szimmetrikus tápfeszültségről üzemel.2db 3300Mf 25V és 2db 8200Mf 63V pufferrel.Gondoltam megkínálom +-15V és +-42v-al,de ha esetleg valaki ismeri a gyárit maradnék az eredeti értékeknél.
Hátha valaki tudna segíteni.Köszönöm.
Üdv!
I have a Yamaha CDX-590 CD player and it skips on some CDs - original CDs, these CDs play without problems on my other CD players.
I have changed the laser unit (KSS-210A) but this didn't solve the problem.
When I turn the player upside down, it plays the problematic CDs without a problem.
That's why I think the laser needs adjustment.
I have only a service manual for the CDX-493/593 but they should be very similar to the CDX-590.
It seems that the adjustments are done via "test mode" of the CDX-590, unfortunately there is not much information, how to exactly, in the service manual.
Here is a picture of the PCB.
http://www.volny.cz/hwtest/PCB.JPG
Here are the "test mode" sections of the service manual.
http://www.volny.cz/hwtest/TM1.GIF
http://www.volny.cz/hwtest/TM2.GIF
In "test mode" I have tried Auto adjustment mode 1, 2, 3, but I don't know if it should work fully automatic without any intervention or when the mode is fineshed and I can proceed to the next one.
So I activated mode 1, waited a while, activated mode 2, waited a while, activated mode 3, then exited test mode.
It didn't help.
Mode 1 - only a short blink of two horizontal dashes on the display and thats it
Mode 2 - started "play" without sound from a strange time 99:00 (the test CD is not so long), after a while it skips to another time, "plays" a while, then skips back and "plays" and so on, I left it about an hour and it was still going on
Mode 3 - seems to be very short as mode 1
I think I'm missing something ...
Maybe someone did this or even serviced Yamahas in an official service and can provide information how to adjust the laser?
Or maybe the problem is not the laser?
Sziasztok!
Van nekem egy 1995-ben vásárolt Yamaha PSR-510 amatőr (tehát nem profi zenészek használják) szintetizátorom aminek a fejhallgató és az AUX kimenetének ugyanaz a csatlakozója.
Laikusként én azt szeretném megérteni, hogy ez hogyan lehetséges, mert amikor a fejhallgatót bedugom ebbe a csatlakozó aljzatba (amikor is a szinti hangszórói elnémulnak), attól kezdve a szinti hangerő szabályzó gombjával tudom a fejhallgató hangerejét is szabályozni.
Én idáig úgy tudtam, hogy az AUX kimenet jele egy stabil volt illetve mV tartományba esik, amit nem szoktak és nem is lehet változtatni azért, hogy a hozzá kötött erősítő bemenő elektronikáját véletlenül se tudja károsítani.
De ebben az esetben a hangerő szabályzó gomb pont ezt teszi.
(Nem feltételezem, hogy ennek a kimenő áramkörnek lenne egy spéci áramköre kizárólag arra a célra, hogy detektálja, hogy fejhallgató vagy erősítő van-e az aljzatba bedugva.)
Tehát, mit tanácsoltok nekem ez ügyben? Pl. hová állítsam a hangerő szabályzó lineáris potiját ha a szintit egy erősítőhöz akarom kötni?
Van nekem egy nagyon érzékeny Fluke 87-es DVOM voltmérőm, azzal tudnék a csatlakozón feszültséget mérni ha ez segítene, de engem leginkább egy olyan megoldás nyugtatna meg végleg ha egy hozzáértő szakember adna hozzá egy valódi AUX kimenetet néhány forrasztással a megfelelő helyen.
De várom a javaslataitokat. A szerviz manualt le lehet tölteni innen az elektrotanyáról, az utolsó oldalán láttam a legjobb ábrázolását ennek az áramkörnek.
Sziasztok.
Van egy yamaha rx-v450-es erősítőm amit elég rég nem használtam.
Most próbáltam ismét használatba venni, de sajnos lett vele valami.
Egy kis használat után random újraindulgat.
Valamikor el sem tud indulni.
Indulásnál behúz benne egy relé majd ki is kapcsol, ismét behúz majd ismét elejt.
Áramtalanítom várok egy picit akkor elindul, de kis idő után ismét kezd újraindulni.
Valamikor 10 percig megy, de valamikor csak 1 percig.
Van valakinek esetleg ötlete, hogy mi fáradhatott el benne?
