Üdv mesterek. Minedene jól müködik a gépen,és gyönyörü hangja van,,,,, de mint irtam , bizonyos idöközönként ,,, elhallgat 1-2-3 másodpercre , visszajön a hang de dadodva - szaggatva. Közben amikor kikapcsol a hang akkor kattogo hangot lehet hallani, mint valami relé kattogna/letiltana 1-2 másodpercre.Van úgy , hogy 1 óra után kezdi de van , hogy 5 perc után. Erre kérnék segitséget .
A képen bejelöltem honnan hallom a kattanást.
üdv campes.
https://ibb.co/WWpJxtw
https://ibb.co/qFS1N6T
üdv ismét mindenkinek.
Eddig jutottam . most teljesen tanácstalan vagyok.
a POWER SUUPLY bemérve. ugyanazokat az értékeket mértem mint az AUDIOKARMA oldalon egy ugyan ilyen készüléken megadtak.
https://audiokarma.org/forums/index.php?threads/kenwood-kr-4200-repair-notes.628534/
Here are the power supply voltages I had after completing the board:
Pin 01 5mv
Pin 02 24.85v
Pin 03 24.85v
Pin 04 14.65v
Pin 05 -0.2mv
Pin 06 0v
Pin 07 32.65v (35v Nominal)
Pin 08 44.9v - - - - -- - itt volt csak eltérés 50 volt nálam.
Pin 09 10.24v (10v Nominal)
Pin 10 0v
Pin 11 0v
A MAIN AMP - nál kivettem a C17 - C18-C19 -C 20 kondenzátort és megnéztem ESR -mérövel - jók.
https://ibb.co/w6MZnFq
https://ibb.co/VDBzvmh
https://ibb.co/VWxW07v
https://ibb.co/5WdtDHr
A 2DB ELNA (bilincses) 3300uF 35v elko megmérve ESR -mérövel.
https://ibb.co/6rtHNNB
https://ibb.co/4f383rb
A végfokozat tranyok ( 4 db NEC ) megmérve. + 27 volt a kettö középsö - a két szélsö - 27 v
RELÉN a V06B dióda megmérve. az is jó. a dióda Anod és a Katod oldalán is 50 voltot mértem.
Hát eddig jutottam,,,, és nincs tovább.
Annak a mesternek/mestereknek aki/akik már találkozott/találkoztak ezzel a hibával , akkor az ö/ök segitségét nagyon megköszönném.
üdv.
ISMÉTELTEN , MEGKÖSZÖNÖM ,,,, JACA MESTER ÉS ZSUGORI MESTER ÖNZETLEN ÉS KITARTÓ SEGÍTSÉGÉT!
MESTEREK - KÉSZÜLÉKEK 3 : 0
Hello!
A fenti erősítőnek a trafója primeroldal szakadt.A rajzon azt látom hogy a váltó feszültség 2x50V De azt én sokallom.Tud ebben valaki segíteni hány volt a váltó feszültség? Továbbá hol lehet beszerezni? A méret ami belefér korlátozott.
This is a compact design to I guess transfer the vinyl into MP3 format.
Complaint was when the arm was moved the tt dont spin, confirmed that as
theres a leaf switch to sense arm movement,
and its fed to a main pcb with all the IC's that I guess handle all the
stuff. The switch is ok, and I remember seeing 14V or so on the motor pins
frm the PCB, so I figured perhaps theres anough current to spin the motor and
focused on testing the motor.
Manufacturer does not supply the mainboard that feeds the motor but
the motor can be taken apart and after I opened it and
disconnected the small pcb fron the motor terminals and apply power
directly, it spins w 12v. theres a small electrolytic cap on the pcb 25V / 22uF and an
AN6652 4 pin T0-220 type case IC that I guess is some kind of speed control
circuitry.
The drive Motor is an EG-530-SD-3F, main board is stamped K-13007.
Gonna check the cap, but after searching this IC and its
applications with the motor, I see its popular and some drawings show how its used to regulate the 78,33
and 45 rpm speeds.
This drawing looks pretty much what I see in there:
https://tectronelectronics.eu/images/thumbnails/465/465/detailed/31/eg530.jpg
I have replaced the IC and the cap, but the motor still does not turn. The main pcb
is proprietary and cant be purchased, and I think it is giving the op-amp IC a reference signal.
Is there a way to bypass that signal or fool the IC to believing its on to test it out?
Photo showing the motor pcb :
http://www.mediafire.com/view/s79blgku1503mtg/HPIM0643.JPG/file
Photo of motor under test:
http://www.mediafire.com/view/thhgvcwac8al7gu/HPIM0635.jpg/file
Üdv!
Ismét megpróbálom, hátha... Sajnos betörték (kijelző, minden más OK), ha lenne valakinek bontott ilyen készüléke, vevő lennék a plexijére, vagy a komplett előlapra: http://www.kephost.com/view3.php?filename=56lgkrzav1uuxvx7gxz2.jpg
HCD-RG55S (MHC-RG55S)
THX.
