Sziasztok!
Hoztak 2 db mono házigyártmányu QUAD-ot, az egyiket mintának mert az jó.A másikban azonnal kiég a végtranzisztor MJ 15003 (TO-3), meg az egyik meghajtója BD246C.Tápja kb 500VA toroid transzformator 2x44000uF elkókkal, tápja stabil ±56V. Az OP LT318 fémtokos volt, az is rossz volt.
Beraktam uj MJ15003-at kiégett, meg elégett a NYAK-on egy pár helyen a vezeték ezek után olcsobb 2N3055-öt tettem bele az is azonnal kiégett.
Most OP helyett TL081-et, majd mostmár TL071-et, ezen az OP-n 6-os kimeneten 1.1V helyett -8.8V van, ha kiakasztom a hangszóró kimenetrôl a visszacsatolást (R5=4k7) akkor -14V-om van, de ez átsétál lassan +14V-ra, OP tápja ZY15-el stabilizálva van de nekem 15.9V,-15.6V van, próbáltam a pl.negatív tápot (mivel nincs duplatápom) külsô táppal kiegyenliteni de a 6-os kimenet nem változott.
Tr2 kolektorán +54V (jó?)
Tr1,Tr3,Tr4 emiterjein +54V (rossz)
Végfok bázisokon +54V (rossz)
A rajz ehhez hasonlo de gyengített nincs benne a Tr5, Tr6, az OP kimenetén nincs D8 zener,D9 zener.
http://img15.imagefra.me/i83f/shizo/vrfk_108_uef0y.jpg
SZIASZTOK. KERESNÉK LG MIKROHIFI-HEZ KAPCSOLÁSI RAJZOT.
SZERENCSÉMRE LEÉGETT A HÁLÓZATI TRAFOJA. NEM TUDOM A FESZEKET HOGY MIT AD LE VÁLTOBA!KÉSZÜLÉK TIP.LG-M330.
HA VALAKI TUD SEGITENI MEGKÖSZÖNNÉM. ÜDV.ROBI69@PR.HU
Üdv!
Ford FB6000CD rádióban meghibásodott a végfok!
Az eredeti: 70055AB/philips/ Ami helyettesítené, az pedig TDA8587J típusú!
Tudnátok segíteni a beszerzésben? Bontott példánnyal is segítenétek!
Köszi: Pozsgai
Keresnék megvételre, a fenti autós CD-hez távirányítót, és előlap keretet.
Tudom, hogy rendelhető, de túl sokat nem költenék rá. Saját készülékem, és most cseréltem benne szallagkábelt, ezért használt, vagy hibás érdekelne.
