Harman Kardon 161S updated SMPS schematic

Hello Everyone. Can anyone help me find the updated SMPS schematic for AVR161S Harman Kardon. Because the IC 92 of the SMPS board that I have is different from the IC 92 in the available service manual. The one mentioned in the service manual is ICE2B265 which is 8 pin PWM and the one that i have in my SMPS board is a 6 pin PWM with the number 63144a. The other reason i am looking for an updated schematic is I need to find the value of 2 diodes which is also not mentioned in the available schematic. Thanks in advance.
